| Manufacturer | TIANMA |
| Model Name | TM150TDSG70 |
| Screen Size | 15 inch |
| Pixel Number | 1024(RGB)×768 , XGA |
| Active Area(mm) |
304.128(W) x 228.096 (V)
|
| Outline(mm） |
326.5(H)×253.5 (V) ×11.8 (D)
|
|
Pixel pitch(mm)
|
0.297(H) × 0.297(V)
|
| Treatment |
Anti Glare
|
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.) |
| Response | 8 (Typ.)(Tr/Td) ms |
| Work Mode | TN , Normally white, Transmissive |
| Color Depth | 262K/16.7M , 60% NTSC |
| Backlight | WLED, 30K hours,with LED Driver |
| Net Weight | 1.00Kgs |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
TIANMA Original Package; 14 pcs/box; weight : 14.6Kgs; size : 378（L）x 368（W）x 315.5（H） |
