| Manufacturer | TIANMA |
| Model Name | TM121SDS01 |
| Screen Size | 12.1 inch |
| Pixel Number | 800(RGB)×600 , SVGA |
| Active Area(mm) | 246.0 x 184.5 (H×V) |
| Outline(mm） | 279.0 X 209.0 X 9.0 (H×V×D) |
| Pixel pitch(mm) | 0.3075 x 0.3075 (H×V) |
| Treatment | Anti Glare |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 700 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/65/75(CR≥10) Left / Right/UP /Down |
| Response | 10/25 (Typ.)(Tr/Td) ms |
| Work Mode | TN , Normally white, Transmissive |
| Color Depth | 262K/16.7M , 55% NTSC |
| Backlight | WLED , 50K hours,with LED Driver |
| Net Weight | 540g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package | TIANMA Original Package |
