| Manufacturer | TIANAM |
| Model Name | P1210XGF1MA01 |
| Screen Size | 12.1 Inch |
| Pixel Number | 1024(RGB)×768 , XGA |
| Active Area(mm) | 245.76 x 184.32 (H×V) |
| Outline(mm） | 260.5 x 203.0 x 9.5 (H×V×D) |
| Pixel Pitch(mm) | 0.240 x 0.240 (H×V) |
| Treatment | AG |
| Luminance | 800 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88(CR≥10) Left / Right/UP /Down |
| Response | 25/25 (Typ.)(Tr/Td) ms |
| Work Mode | SFT , Normally black, Transmissive |
| Color Depth | 262K/16.7M , 72% NTSC |
| Backlight | WLED , 70K hours, with LED Driver |
| Net Weight | 550g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -40 ~ +90 (°C) Operating Temp.: -30 ~ +80 (°C) |
| Package | TIANMA Original Package |
