| Manufacturer | TIANMA |
| Model Name | TM104TDGP10 |
| Screen Size | 10.4 inch |
| Pixel Number | 1024(RGB)×768 , XGA |
| Active Area(mm) | 210.432 x 157.824 (H×V) |
| Outline(mm） | 230.00 x 175.80 x 5.70 (H×V×D) |
| pixel Pitch(mm) | 0.2055 x 0.2055 (H×V) |
| Treatment |
Anti-Glare
|
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85(CR≥10) Left / Right/UP /Down |
| Response | 35 (Typ.)(Tr/Td) ms |
| Work Mode | SFT , Normally black, Transmissive |
| Color Depth | 262K/16.7M , 50% NTSC |
| Backlight | WLED , 50K hours, with LED Driver |
| Net Weight | 430G |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
TIANMA Original Package; 18 pcs/ctn; weight : TBD; size : 544(L)mm x 365(W)mm x 250(H)mm |
