| Manufacturer | TIANMA |
| Model Name | P0840XGF1MB00 |
| Screen Size | 8.4 inch |
| Pixel Number | 1024(RGB)×768 , XGA |
| Active Area(mm) | 170.496 x 127.872 (H×V) |
| Outline(mm） | 199.5 x 149.0 x 9.7 (H×V×D) |
| Pixel pitch(mm) | 0.1665 x 0.1665 (H×V) |
| Treatment | AG |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88(CR≥10) Left / Right/UP /Down |
| Response | 25/30 (Typ.)(Tr/Td) ms |
| Work Mode | SFT, Normally white, Transmissive |
| Color Depth | 262K/16.7M |
| Backlight | WLED , 50K hours,withLED Driver |
| Net Weight | 301g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -40 ~ +90 (°C) Operating Temp.: -30 ~ +80 (°C) |
| Package |
TIANMA Original Package; 20 pcs/ctn; weight : 10.95Kgs; size : 544(L)mm x 365(W)mm x 250(H)mm |
