| Manufacturer | TIANMA |
| Model Name | TM080TDGP02 |
| Screen Size | 8 inch |
| Pixel Number | 1024(RGB)×768 , XGA |
| Active Area(mm) | 162.05 x 121.54 (H×V) |
| Outline(mm） | 183.43 x 1388.35 x 3.75 (H×V×D) |
| Pixel pitch(mm) | 0.158 x 0.158 (H×V) |
| Treatment | AG |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 1800 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.) |
| Response | 35 (Typ.)(Tr/Td) ms |
| Work Mode | SFT , Normally black, Transmissive |
| Color Depth | 16.7M , 50% NTSC |
| Backlight | WLED, 30K hours,without driver |
| Net Weight | TBD |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 8-bit) , 40 pins , FPC |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
TIANMA Original Package; 36 pcs/ctn; weight : 12.1Kgs; size : 544(L)mm x 365(W)mm x 250(H)mm |
