| Manufacturer | TIANMA |
| Model Name | TM070RDH10-40 |
| Screen Size | 7 inch |
| Pixel Number | 800(RGB)×480, WVGA |
| Active Area(mm) |
154.08 (W) x 85.92 (H×V)
|
| Outline(mm） |
164.9 x 100 x 5.7 (H×V×D)
|
|
Pixel pitch(mm)
|
0.1926 x 0.179 mm (H×V) |
| Treatment |
Anti Glare
|
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/60/80 (CR≥10) Left / Right/UP /Down |
| Response | 15 (Typ.)(Tr/Td) ms |
| Work Mode | TN, Normally white, Transmissive |
| Color Depth | 262K/16.7M , 50% NTSC |
| Backlight | WLED , 20K hours,without driver |
| Net Weight | 160g |
| Touchscreen | without |
| Signal Type/interface Type | Parallel RGB (1 ch, 6/8-bit) , FPC , 50 pins |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
TIANMA original package; 50 pcs/ctn; weight : TBD; size : 530(L)mm x 350(W)mm x 250(H)mm |
