| Manufacturer | TIANMA |
| Model Name | TM043NDH02-40 |
| Screen Size | 4.3 inch |
| Pixel Number | 480(RGB)×272 ,WQVGA |
| Active Area(mm) | 95.040 x 53.856 (H×V) |
| Outline(mm） | 105.50 x 67.20 x 2.9 (H×V×D) |
| Pixel Pitch(mm) | 0.198 x 0.198 (H×V) |
| Treatment | AG |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/60 (Typ.) |
| Response | 20 (Typ.)(Tr/Td) ms |
| Work Mode | TN, Normally white, Transmissive |
| Color Depth | 16.7M , 50% NTSC |
| Backlight | WLED , 30K hours,without driver |
| Net Weight | 44.4g |
| Touchscreen | without |
| Signal Type/interface Type | Parallel RGB (1 ch, 8-bit) , FPC , 40 pins |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
TIANMA original package; 144 pcs/ctn; weight : 8.0kgs; size : 544(L)mm x 365(W)mm x 250(H)mm |
