| Manufacturer | TIANMA |
| Model Name | P0350QVF1ME00 |
| Screen Size | 3.5 inch |
| Pixel Number | 320(RGB)×240, QVGA |
| Active Area(mm) |
70.08 x 52.56 (H×V)
|
| Outline(mm） |
76.9 x 63.9 x 3.15 (H×V×D)
|
| Pixel Pitch(mm) | 0.219 x 0.219 (H×V) |
| Treatment |
HC
|
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.) |
| Response | 25 (Typ.)(Tr/Td) ms |
| Work Mode | SFT , Normally black, Transmissive |
| Color Depth | 16.7M , 60% NTSC |
| Backlight | WLED, 30K hours,without driver |
| Net Weight | 31.0g |
| Touchscreen | without |
| Signal Type/interface Type | Parallel RGB (1 ch, 8-bit) + SPI , 54 pins , FPC |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
TIANMA Original Package; 252 pc/ctn; weight : 13.5 kgs; size : 544(H)mm x 365(V)mm x 250(D)mm |
