| Manufacturer | IVO |
| Model Name | M101GWT9 R3 |
| Screen Size | 10.1 INCH |
| Pixel Number | M101GWT9 R3 |
| Active Area(mm) | 222.72 x 125.28 (H×V) |
| Outline(mm） | 244.0 x 143.0 x 12.9 (H×V×D) |
| Pixel Pitch(mm) | 0.2175 x 0.2175 (H×V) |
| Treatment | Anti-glare , Hard-Coating (3H) |
| Luminance | 640 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80(CR≥10) Left / Right/UP /Down |
| Response time | 16 (Typ.)(Tr/Td) ms |
| Display Mode | TN , Normally white , Transmissive |
| Color Depth | 262K/16.7M , 50% NTSC |
| Backlight | WLED, 50K hours, with LED Driver |
| Net Weight | 440g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Voltage Supply | +3.3 V |
| Max. Ratings |
Storage Temp.: -40 ~ +95 (°C) Operating Temp.: -30 ~ +85 (°C) |
| Package |
IVO Original package; 36 pcs/ctn |
