| Manufacturer | IVO |
| Model Name | M080AWT8 R1 |
| Screen Size | 8 inch |
| Pixel Number | 1024(RGB)×600 , WSVGA |
| Active Area(mm) | 176.64 x 99.36 (H×V) |
| Outline(mm） | 192.8 x 116.9 x 6.4 (H×V×D) |
| Pixel Pitch(mm) | 0.1725 x 0.1656 (H×V) |
| Treatment | Anti-glare |
| Luminance | 670 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 75/75/70/75(CR≥10) Left / Right/UP /Down |
| Response time | 16 (Typ.)(Tr/Td) ms |
| Display Mode | TN , Normally white , Transmissive |
| Color Depth | 262K/16.7M , 72% NTSC |
| Backlight | WLED , 30K hours , without Driver |
| Net Weight | 240g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 40 pins , FPC |
| Voltage Supply | +3.3 V |
| Max. Ratings |
Storage Temp.: -40 ~ +90 (°C) Operating Temp.: -30 ~ +85 (°C) |
| Package |
IVO Original package; 40 pcs/ctn |
