| Manufacturer | IVO |
| Model Name | M070SWP1 R4 |
| Screen Size | 7 inch |
| Pixel Number | 800(RGB)×480 , WVGA |
| Active Area(mm) | 153.60 x 86.64 (H×V) |
| Outline(mm） | 165.0 x 104.0 x 5.0 (H×V×D) |
| Pixel Pitch(mm) | 0.192 x 0.1805 (H×V) |
| Treatment | Antiglare , Hard-Coating (3H) with EWV film |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/50/60(CR≥10) Left / Right/UP /Down |
| Response time | 16 (Typ.)(Tr/Td) ms |
| Display Mode | TN , Normally white , Transmissive |
| Color Depth | 16.7M , 50% NTSC |
| Backlight | WLED , 50K hours , with LED Driver |
| Net Weight | 136g |
| Touchscreen | without |
| Signal Type/interface Type | TTL (1 ch, 8-bit) , FPC , 60 pins |
| Voltage Supply | +3.3 V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package | IVO Original package |
