| Manufacturer | Innolux |
| Model Name | AT070TN83 V.1 |
| Screen Size | 7 inch |
| Pixel Number | 800(RGB)×480 , WVGA |
| Active Area | 152.4 (W) x 91.44 (H) mm |
| Outline | 165(W) x 104(H) x 5.5(D) mm |
| Treatment | AG |
| Luminance | 300 cd/m² |
| Contrast Ratio | 500:1 |
| Viewing Angle | 70/70/50/70 |
| Response time | 10/15ms |
| Work Mode | TN , Normally White , Transmissive |
| Color Depth | 262K |
| Backlight | WLED , 20K Hours , with LED driver |
| Net Weight | 130g |
| Touchscreen | without |
| Signal Type/interface Type | TTL (1 ch, 6-bit) , 40 pins |
| Voltage Supply | +3.3 V |
| Temperature |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
Innolux original package; 50 pcs/carton; Carton size: 530x355x255 mm; Gross weight: 9.528Kgs(Typ.) |
