| Manufacturer | Innolux |
| Model Name | AT056TN52 V.3 |
| Screen Size | 5.6 inch |
| Pixel Number | 640(RGB)×480 , VGA |
| Active Area(mm) | 112.896 (W) x 84.672(H) |
| Outline(mm） | 126.5(W) x 100(H) x 5.7(D) |
| Dot pitch(mm) | 0.0588(W) x 0.1764(H) |
| Treatment | Anti-Glare |
| Luminance | 200 cd/m² |
| Contrast Ratio | 500:1 |
| Viewing Angle | R/L/U/D 70/70/50/70(Deg) |
| Response | 10/15ms |
| Work Mode | TN , Normally White , Transmissive |
| Color Depth | 16.7M |
| Backlight | WLED , 20k hours , withour driver |
| operating temperature | -20 ~ +70 (°C) |
| storage temperature | -30 ~ +80 (°C) |
| Touchscreen | without |
| Signal Type/interface Type | Parallel RGB (1 ch, 8-bit) , FPC , 50 pins |
| Voltage Supply | +3.3 V(Typ.) |
| weight | 127.5g |
| Package |
Innolux original package; 60 pcs/carton; Carton size: 530(L) x 355(W) x 255(H)mm; Weight: 10.306kgs. |
