| Manufacturer | Innolux |
| Model Name | G238HCJ-LH1 |
| Screen Size | 23.8 inch |
| Pixel Number | 1920(RGB)×1080 , Full HD |
| Active Area(mm) | 527.04 × 296.46 (H×V) |
| Outline(mm） | 543 × 317.4 × 19.425 (H×V×D) |
| Pixel Pitch(mm) | 0.2745 × 0.2745 (H×V) |
| Treatment |
AG type, 3H hard coating, Haze 25
|
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (CR≥10) Left / Right/UP /Down |
| Response time | 14/11 (Typ.)(Tr/Td) ms |
| Display Mode | AAS , Normally black , Transmissive |
| Color Depth | 16.7M , 74% NTSC |
| Backlight | WLED , 50K hours , with LED Driver |
| Net Weight | 2.82Kgs |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (2 ch, 8-bit) , 30 pins |
| Voltage Supply | +5.0 V |
| Max. Ratings |
Storage Temp.: -40 ~ +80 (°C) Operating Temp.: -30 ~ +80 (°C) |
| Package |
Innolux Original package; 10 pcs/ctn; weight : 30.4Kgs; size : 620(L) x 348(W) x 430(H) mm |
