| Manufacturer | Innolux |
| Model Name | G185BGE-L01 |
| Screen Size | 18.5 Inch |
| Pixel Number | 1366(RGB)×768 , WXGA |
| Active Area(mm) | 408.9 × 230.4 (H×V) |
| Outline(mm） | 4430.37 × 254.6 × 16.1 (H×V×D) |
| Pixel Pitch(mm) | 0.3 ×0.3 (H×V) |
| Treatment |
AG type, 3H hard coating, Haze 25
|
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (CR≥10) Left / Right/UP /Down |
| Response time | 1.5/3.5 (Typ.)(Tr/Td) ms |
| Display Mode | TN , Normally white , Transmissive |
| Color Depth | 16.7M , 72% NTSC |
| Backlight | WLED , 50K hours, with LED Driver |
| Net Weight | 1.65Kgs |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 8-bit) , 30 pins |
| Voltage Supply | +5.0 V |
| Max. Ratings |
Storage Temp.: -20 ~ +60 (°C) Operating Temp.: 0 ~ +60 (°C) |
| Package |
Innolux Original package; 8 pcs/box; weight : 21.0Kgs; size : 525(L) x 284(W) x 360(H)mm |
