| Manufacturer | INNOLUX |
| Model Name | G156BGE-L03 |
| Screen Size | 15.6 inch |
| Pixel Number | 1366(RGB)×768 , WXGA |
| Active Area(mm) | 344.232 x 193.536 (H×V) |
| Outline(mm） | 363.8 x 215.98 x 9.3 (H×V×D) |
| Pixel Pitch(mm) | 0.252 x 0.252 (H×V) |
| Treatment |
AG type, 3H hard coating
|
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 600 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80(CR≥10) Left / Right/UP /Down |
| Response time | 3/8 (Typ.)(Tr/Td) ms |
| Display Mode | TN , Normally white , Transmissive |
| Color Depth | 16.7M , 63% NTSC |
| Backlight | WLED , 50K hours , with LED Driver |
| Net Weight | 755g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 8-bit) , 30 pins |
| Voltage Supply | +5.0 V |
| Max. Ratings |
Storage Temp.: -20 ~ +60 (°C) Operating Temp.: -10 ~ +60 (°C) |
| Package |
Innolux Original package; 13 pcs/ctn; weight : 12.0Kgs; size : 465 (L) x 362 (W) x 314 (H) mm |
