| Manufacturer | Innolux |
| Model Name | R150XJE-L01 |
| Screen Size | 15 inch |
| Pixel Number | 1024(RGB)×768 , XGA |
| Active Area(mm) | 304.1 x 228.1 (H×V) |
| Outline(mm） | 326.5 x 253.5 x 9.1 (H×V×D) |
| Pixel Pitch(mm) | 0.297 x 0.297 (H×V) |
| Treatment | Hard Coating (3H) , Anti-Glare |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 2500 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85(CR≥10) Left / Right/UP /Down |
| Response time | 15/10 (Typ.)(Tr/Td) ms |
| Display Mode | Super MVA , Normally black , Transmissive |
| Color Depth | 262K/16.7M , 72% NTSC |
| Backlight | WLED , 50K hours , with LED Driver |
| Net Weight | 750g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Voltage Supply | +3.3 V |
| Max. Ratings |
Storage Temp.: -25 ~ +65 (°C) Operating Temp.: -10 ~ +65 (°C) |
| Package |
Innolux Original package; 12 pcs/box; weight : 11.97Kgs; size : 489(L) x 382(W) x 320(H) mm |
