| Manufacturer | Innolux |
| Model Name | G150XNE-L01 |
| Screen Size | 15.0 inch |
| Pixel Number | 1024(RGB)×768 , XGA |
| Active Area(mm) | 304.1 (H) x 228.1(V) |
| Outline(mm） | 326.5(H) x 253.5(V) x 9.1(D) |
| Treatment | Hard Coating (3H), Anti-Glare |
| Luminance | 500 cd/m² |
| Contrast Ratio | 2500:1 |
| Viewing Angle | 88/88/88/88 |
| Response | 13/5ms |
| Work Mode | NPVA, Normally Black, Transmissive |
| Color Depth | 262K/16.7M , 72% NTSC |
| Backlight | WLED , 70k Hours , With LED driver |
| Net Weight | 960g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Voltage Supply | +3.3 V |
| Temperature |
Storage Temp.: -40 ~ +80 (°C) Operating Temp.: -30 ~ +80 (°C) |
| Package |
Innolux original package; 16 pcs/ctn; weight : 18.0Kgs; size : 511 (L)mm x 420 (W)mm x 360 (H)mm |
