| Manufacturer | INNOLUX |
| Model Name | G150XJE-E01 |
| Screen Size | 15 inch |
| Pixel Number | 1024(RGB)×768 , XGA |
| Active Area(mm) | 304.1 x 228.1 (H×V) |
| Outline(mm） | 326.5 x 253.5 x 9.1 (H×V×D) |
| Pixel Pitch(mm) | 0.297 x 0.297 mm (H×V) |
| Treatment |
Hard Coating (3H), Anti-Glare
|
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88(CR≥10) Left / Right/UP /Down |
| Response time | 16/7 (Typ.)(Tr/Td) ms |
| Display Mode | NPVA , Normally black, Transmissive |
| Color Depth | 262K/16.7M , 72% NTSC |
| Backlight | WLED, 70K hours, with LED Driver |
| Net Weight | 980g |
| Touchscreen | without |
| Signal Type/interface Type | eDP (1 Lane) , eDP1.2 , 30 pins |
| Voltage Supply | +3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +70 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
Innolux Original package; 16 pcs/ctn; weight : 16.7Kgs; size : 511(L)mm x 420(W)mm x 360(H)mm |
