| Manufacturer | Innolux |
| Model Name | G121XCE-LM1 |
| Screen Size | 12.1 inch |
| Pixel Number | 1024(RGB)×768 , XGA |
| Active Area(mm) | 245.76 x 184.32 (H×V) |
| Outline(mm） | 260.5 x 204 x 8.4 (H×V×D) |
| Pixel Pitch(mm) | 0.24 x 0.24 (H×V) |
| Treatment |
Hard coating (3H), Anti-Glare
|
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89(CR≥10) Left / Right/UP /Down |
| Response time | 13/12 (Typ.)(Tr/Td) ms |
| Display Mode | AAS , Normally black, Transmissive |
| Color Depth | 262K/16.7M , 72% NTSC |
| Backlight | WLED, 50K hours, with LED Driver |
| Net Weight | 510g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Voltage Supply | +3.3V |
| Max. Ratings |
Storage Temp.: -40 ~ +80 (°C) Operating Temp.: -30 ~ +75 (°C) |
| Package |
Innolux Original package; 18 pcs/ctn; weight : 10.9Kgs; size : 465 (L)mm x 362 (W)mm x 314 (H)mm |
