| Manufacturer | Innolux |
| Model Name | G121XCE-L01 |
| Screen Size | 12.1 inch |
| Pixel Number | 1024(RGB)×768 , XGA |
| Active Area(mm) | 245.76 x 184.32 (HxV) |
| Outline(mm） | 260.5(W) x 204.0(V) x 8.4(D) |
| Bezel Area(mm) | 249.0 x 187.5 (HxV) |
| Treatment | Hard coating (3H) , Anti-Glare |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89(CR≥10) Left / Right / Up / Down |
| Response | 13/12 (Typ.)(Tr+Td) ms |
| Work Mode | AAS , Normally black , Transmissive |
| Color Depth | 262K/16.2M , 72% NTSC |
| Backlight | WLED , 50K hours , With LED Driver |
| Net Weight | 510g |
| operating frequency | 60Hz |
| Touchscreen | Without, RTP+CTP for options |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 20 pins |
| Voltage Supply | +3.3 V (Typ.) |
| Temperature |
Storage Temp.: -40 ~ +90 (°C) Operating Temp.: -30 ~ +85 (°C) |
| Package |
Innolux original package; 18 pcs/ctn; weight : 10.9 Kgs; size : 465 (L) mm x 362 (W) mm x 314 (H) mm |
