| Manufacturer | Innolux |
| Model Name | G121ICE-L01 |
| Screen Size | 12.1 inch |
| Pixel Number | 1280(RGB)×800 , WXGA |
| Active Area(mm) | 261.12 x 163.2 (H×V) |
| Outline(mm） | 278 x 184 x 10 (H×V×D) |
| Pixel Pitch(mm) | 0.204 x 0.204 (H×V) |
| Treatment |
AG type, 3H hard coating
|
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85(CR≥10) Left / Right/UP /Down |
| Response time | 12/8 (Typ.)(Tr/Td) ms |
| Display Mode | AAS , Normally black, Transmissive |
| Color Depth | 262K/16.7M , 72% NTSC |
| Backlight | WLED, 50K hours, with LED Driver |
| Net Weight | 490g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 30 pins |
| Voltage Supply | +3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +85 (°C) Operating Temp.: -30 ~ +80 (°C) |
| Package |
Innolux Original package; 20 pcs/ctn; weight : 17.0Kgs; size : 465(L)mm x 362(W)mm x 314(H)mm |
