| Manufacturer | INNOLUX |
| Model Name | G104ACJ-L01 |
| Screen Size | 10.4 inch |
| Pixel Number | 960(RGB)×1280 , Quad-VGA |
| Active Area(mm) | 158.4 x 211.2 (H×V) |
| Outline(mm） | 173.4 x 228.7 x 13.77 (H×V×D) |
| Pixel Pitch(mm) | 0.165 x 0.165 (H×V) |
| Treatment |
Hard coating (3H), Anti-Glare
|
| Luminance | 900 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85(CR≥10) Left / Right/UP /Down |
| Response time | 13/12 (Typ.)(Tr/Td) ms |
| Display Mode | AAS , Normally BLACK, Transmissive |
| Color Depth | 262K/16.7M , 50% NTSC |
| Backlight | WLED, 50K hours, without Driver |
| Net Weight | 470g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 8-bit) , 50 pins |
| Voltage Supply | +3.3V |
| Max. Ratings |
Storage Temp.: -40 ~ +90 (°C) Operating Temp.: -40 ~ +85 (°C) |
| Package |
Innolux Original package; 18 pcs/ctn; size : 490(L)mm x 350(W)mm x 320(H)mm; weight : 10.1Kgs |
