| Manufacturer | Innolux |
| Model Name | AT102TN03 V.9 |
| Screen Size | 10.2 inch |
| Pixel Number | 800(RGB)×480 , WVGA |
| Active Area(mm) | 222.0 x 132.48 (H×V) |
| Outline(mm） | 235.0 x 145.8 x 6.1 (H×V×D) |
| Pixel Pitch(mm) | 0.0925 x 0.276 (H×V) |
| Treatment |
Anti-Glare
|
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 300 : 1 (Typ.) (TM) |
| Viewing Angle | 65/65/45/65(CR≥10) Left / Right/UP /Down |
| Response time | 15/20 (Typ.)(Tr/Td) ms |
| Display Mode | TN , Normally white, Transmissive |
| Color Depth | 262K , 50% NTSC |
| Backlight | WLED, 20K hours, without Driver |
| Net Weight | 325g |
| Touchscreen | without |
| Signal Type/interface Type | TTL (1 ch, 6-bit) , 60 pins , FPC |
| Voltage Supply | +3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +85 (°C) Operating Temp.: -30 ~ +85 (°C) |
| Package |
Innolux Original package; 25 pcs/ctn; size : 530(L)mm x 355(W)mm x 255(H)mm; weight : TBD |
