| Manufacturer | INNOLUX |
| Model Name | AT090TN12 V.3 |
| Screen Size | 9 inch |
| Pixel Number | 800(RGB)×480 , WVGA |
| Active Area(mm) | 198.000 x 111.696 (H×V) |
| Outline(mm） | 211.1 x 126.5 x 5.9 (H×V×D) |
| Pixel Pitch(mm) | 0.0825 x 0.2372 (H×V) |
| Treatment |
Anti-Glare
|
| Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/50/70(CR≥10) Left / Right/UP /Down |
| Response | 10/15 (Typ.)(Tr/Td) ms |
| Work Mode | TN , Normally white, Transmissive |
| Color Depth | 262K/16.7M , 50% NTSC |
| Backlight | WLED , 20K hours, without Driver |
| Net Weight | 253g |
| Touchscreen | without |
| Signal Type/interface Type | TTL (1 ch, 6/8-bit) , FPC , 50 pins |
| Voltage Supply | +3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
Innolux original package; 30 pcs/ctn; weight : 10.462Kgs; size : 530(L)mm x 355(W)mm x 255(H)mm |
