| Manufacturer | AUO |
| Model Name | G190ETN01.2 |
| Screen Size | 19 inch |
| Pixel Number | 1280(RGB)×1024 , SXGA |
| Active Area(mm) | 376.32 × 301.056 (H×V) |
| Outline(mm） | 396 × 324 × 15.68 (H×V×D) |
| Bezel Area(mm) | 379.72 × 304.46 (H×V) |
| Treatment | Hard coating (3H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle |
85/85/80/80 (CR≥10) Left/Right/UP/Down |
| Response | 3 /7 (Typ.)(Tr+Td) ms |
| Work Mode | TN , Normally white , Transmissive |
| Color Depth | 16.7M , 72% NTSC |
| Backlight | WLED , 50K hour , with LED Driver |
| Net Weight | 1.80Kgs (Typ.) |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (2 ch, 8-bit) , 30 pins |
| Voltage Supply | +5.0 V (Typ./Max.) |
| Max. Ratings |
Storage Temp.: -30 ~ +85 (°C) Operating Temp.: -30 ~ +85 (°C) |
| Package |
AUO original package; 8 pcs/ carton; weight : 18.0Kgs; size : 489(L) x 293(W) x 420(H)mm |
