| Manufacturer | AUO |
| Model Name | G156HAN02.302 |
| Screen Size | 15.6 inch |
| Pixel Number | 1920(RGB)×1080 , FHD |
| Active Area(mm) | 344.16(H) x 193.59(V)mm |
| Outline(mm） | 363.8(H) x 215.9(V) x 8.8(D)mm |
| Pixel Pitch(mm) | 0.17925 x 0.17925mm |
| Treatment | Anti-glare , 3H |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 |
| Response | 25 (Typ.)(Tr/Td) ms |
| Work Mode | AHVA, Normally black, Transmissive |
| Color Depth | 16.7M , 99% sRGB |
| Backlight | WLED, 50K hours,withLED Driver |
| Net Weight | 660g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (2 ch, 8-bit) , 30 pins |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~70 °C |
| Package |
AUO Original Package; 16 pcs/ctn; weight : 13.2kgs; size : 450mm(L) x 375mm(W) x 319mm(H). |
