| Manufacturer | AUO |
| Model Name | G156HAN01.0 |
| Screen Size | 15.6 inch |
| Pixel Number | 1920(RGB)×1080 , Full HD |
| Active Area(mm) | 344.16 × 193.59 (H×V) |
| Outline(mm） | 363.8 × 215.9 × 9.3 (H×V×D) |
| Pixel Pitch(mm) | 0.17925 × 0.17925 (H×V) |
| Treatment | Anti-glare , 3H |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (CR≥10) Left / Right/UP /Down |
| Response time | 25 (Typ.)(Tr/Td) ms |
| Display Mode | AHVA , Normally black , Transmissive |
| Color Depth | 16.2M , 72% NTSC |
| Backlight | WLED , 50K hours , with LED Driver |
| Net Weight | 1.04Kgs |
| Touchscreen | without |
| Signal Type/interface Type | eDP (2 Lanes) , 40 pins |
| Voltage Supply | +3.3 V |
| Max. Ratings |
Storage Temp.: -20 ~ +60 (°C) Operating Temp.: -10 ~ +60 (°C) |
| Package |
AUO Original package; 16 pcs/ctn; weight : 16.3Kgs size : 450(L) x 375(W) x 319(H) mm |
