Innolux 12.1 lcd display G121X1-L03 G121X1-L04 EOL notification and replacement
2020-11-05 18:07
Innolux 12.1-inch G121X1-L03 parameters: 1024*768 resolution, 600 brightness, -30~80 working temperature, 80/80/70/70 viewing angle, LVDS interface.
Innolux original factory has stopped production. If you were using G121X1-L03 before, don’t worry, the original factory has already introduced G121XCE-L01 to replace G121X1-L03.
Innolux 12.1-inch G121XCE-L01 parameters: 1024*768 resolution, 600 brightness, -30~85 working temperature, 89/89/89/89 full viewing angle, LVDS interface, can directly replace G121X1-L03, and in the parameters It has been upgraded and is one of the first choices to replace G121X1-L03.
G121X1-L04 parameters: 1024*768 resolution, 500 brightness, -30~70 working temperature, 80/80/70/70/viewing angle, LVDS interface.
This new model can be directly replaced by G121XCE-L02.
Innolux 12.1-inch G121XCE-L02 parameters: 1024*768 resolution, 500 brightness, -30~70 working temperature, 89/89/89/89 full viewing angle, LVDS interface, this model has been upgraded to full viewing angle in terms of viewing angle, others The parameters are basically the same.
If you want to consider replace with other brand screens, you can use BOE EV121X0M-N10. The detailed parameters of this model are: 1024*768 resolution, 500 brightness, 89/89/89/89 full viewing angle, -35~85 Operating temperature, LVDS interface, and parameters of G121XCE-L01 are basically the same, and will have more advantages in price, and the supply more stable.
