G156HAN03.0

Size:

AUO 15.6 inch FHD 1920*1080 tft lcd panel G156HAN03.0 with IPS and eDP

  • G156HAN03.0
  • Module No:G156HAN03.0
  • Brand:AUO
  • Size:15.6 inch
  • Resolution:1920(RGB)×1080[FHD]
  • Brightness:300 cd/m²
  • Viewing angle:89/89/89/89 (Typ.)
  • Interface:eDP (2 Lanes) , eDP1.2 ,30 pins
  • CR:1000:1
  • Operating Temp.: 0 ~ 50(°C)
  • AUO 15.6 inch tft lcd panel G156HAN03.0 with 1920*1080(FHD) resolution , brightness 300 cd/m².This lcd display is working temperature is - 0~ 50 ° C and its storage temperature is - 20~ 60 (° C).Based on its white LED backlight.This model is recommended for industrial use.

    Matched Resistive touch and capacitive touch available.also we have matched HDMI driver board and touch screen.
    AUO 15.6 inch IPS FHD display G156HAN03.0 tft lcd panel with eDP 30 pins and contrast ratio 1000:1.



    Hangzhou LEEHON Technology is one of the main agents of AUO/BOE / Kyocera/ Innolux TFT- LCD module in China mainland, founded in 2009, the products vary from 2.5 to 43 inches, which include GD (Industrial grade), AV (car class), PID (General Application) and other related products etc.,superior quality and competitive price, our products are sold very well in North&South America, Western Europe and Southeast Asia.
    We can supply total set of display solution:
    TFT LCD screen + touch screen + controller board + cables + open frame.
    stock for sale
    long-time supply
    no MOQ
    in fulll range
