G101EVN03.1

Size:

AUO 10.1 inch 1280(RGB)×800 TFT LCD panel G101EVN03.1 with IPS and 1000 nits

  • G101EVN03.1
  • Module No:G101EVN03.1
  • Brand:AUO
  • Size:10.1 inch
  • Resolution:1280(RGB)×800
  • Brightness:1000 cd/m²
  • Viewing angle:85/85/85/85 (Typ.)
  • Interface:40 pins LVDS (1 ch, 6/8-bit)
  • CR:1300:1
  • Operating Temp.: -20 ~ 60 (°C)
  • AUO 10.1 inch tft lcd panel G101EVN03.1 with 1280x800 resolution , brightness1000 cd/m² . Matched resistive touch and capacitive, touch available for your options.This screen has 50000 hours lifetime of backlight , can support long term opertating.This lcd display is working temperature is - 20 ~ 60 ° C and its storage temperature is - 30 ~ 70 ° C. This lcd screen has good view angel.This model is suitable for industrial and outdoor applications.


    Hangzhou LEEHON Technology is one of the main agents of AUO/BOE / Kyocera/ Innolux TFT- LCD module in China mainland, founded in 2009, the products vary from 2.5 to 43 inches, which include GD (Industrial grade), AV (car class), PID (General Application) and other related products etc.,superior quality and competitive price, our products are sold very well in North&South America, Western Europe and Southeast Asia.
    We can supply total set of display solution:
    TFT LCD screen + touch screen + controller board + cables + open frame.
    stock for sale
    long-time supply
    no MOQ
    in fulll range
