G070VAN01.1

Size:

AUO 7 Inch 800x480 WVGA LCD Panel TFT IPS Display For Industry G070VAN01.1 200nits and 30 pins LVDS

  • G070VAN01.1
  • Module No:G070VAN01.1
  • Brand:AUO
  • Size:7 inch
  • Resolution:800(RGB)×480 , WVGA
  • Brightness:200 cd/m²
  • Viewing angle:85/85/85/85 (Typ.)
  • Interface:LVDS (1 ch, 6/8-bit) , 30 pins
  • CR:1300:1
  • Operating Temp.: -20 ~ +70 (°C)
  • AUO 7 inch tft lcd ips panel G070VAN01.1 with 800(RGB)x480 WVGA resolution, brightness 200 cd/m². This lcd display's working temperature is -20 ~ +70 (°C)  and it's storage temperature is -30 ~ +80 (°C). Based on it's white LED backlight. This model is recommended for industrial use.
    Matched resistive touch and capacitive touch available. Also we have matched HDMI driver board and LVDS cables.
    Industrial 7 Inch 800*480 WVGA LCD Screen Original AUO TFT LCD IPS Panel G070VAN01.1 with 200nits, Full View Range and Touchscreen.



    Hangzhou LEEHON Technology is one of the main agents of AUO/BOE / Kyocera/ Innolux TFT- LCD module in China
    mainland, founded in 2009, the products vary from 2.5 to 43 inches, which include GD (Industrial grade), AV (car class),
    PID (General Application) and other related products etc.,superior quality and competitive price, our products are sold
    very well in North&South America, Western Europe and Southeast Asia.

    We can supply total set of display solution:
    TFT LCD screen + touch screen + controller board + cables + open frame.
    stock for sale
    long-time supply
    no MOQ
    in fulll range
